United states stand up pouch packaging machine:
|
Technical data Stand up pouch packaging machine |
|
|
Type: |
Automatic Packing Machine Series |
|
Product model: |
N60S |
|
Product name: |
United states stand up pouch packaging machine |
|
Packing speed: |
10-15 bags/min |
|
Filling range: |
100G - 1000G; accuracy:≦±0.5g/bag, depends on product |
|
Filling system: |
Electric scale |
|
Pouch material |
PE pouch, Pouch with aluminum foil |
|
Bag type: |
Stand up pouch, pouch with zipper |
|
Bag size: |
Length of Length:100~310mm,Width of Bag:100~150mm |
|
Bag socket: |
450 bags max |
|
Sealing method: |
Heat Sealing |
|
Power: |
220V, 50/60HZ, 1.5 KW |
|
Air supply: |
≧0.6Mpa, and 360L/minute (Can be equipped with Air Compressor) |
|
Weight: |
350 KG |
|
Dimension (L*W*H): |
1100*750*2100mm (L*W*H) |
|
Packing: |
2100*1100*980mm |
Thank you!
United states stand up pouch packaging machine:
1. Application: This United states stand up pouch packaging machine is suitable for quantitative weighing, filling, packaging, and sealing of various granular materials. It is suitable for grains, seeds, and other materials. The filling and dispensing are precise with no spillage. The machine is suitable for various types of bags, meeting the needs of large-scale production in the United States.
2. Applicable Bags: Stand-up zipper bags, gusseted bags, flat bags, eight-side seal bags, back seal bags, and irregularly shaped bags.
3. Bag Sizes:
Bag width range: 10-20cm; Bag length range: 12-30cm
4. Technical Parameters: Core model HondaPack-6/8-200G, power 5KW, packaging weight 5-1500g, metering accuracy ≤±1%, packaging speed ≤45 bags/min, compatible with US 220V 60HZ voltage, machine weight 500Kg, overall dimensions 1388×1116×1536mm.
5. Equipment Features: PLC computer control, user-friendly bilingual (Chinese and English) touchscreen operation, ability to store multiple parameter sets, precise dual-servo film pulling, independent temperature control, adaptable to various packaging materials, low-noise operation, supports parameter adjustment without stopping production, reducing production losses.
6. Export Country: This United states stand up pouch packaging machine was purchased by a US customer. It complies with local industrial environmental protection and material packaging standards, requiring no complex modifications to adapt to local production lines. Its precise particle metering function perfectly meets their needs, helping US companies improve production efficiency.
